Spring Shoot Bolt K Type – 140mm Zinc Plated Spring Loaded Bolt
-
Manufactured in the UK -
Zinc Plated Steel
-
Bulk Discounts Available
-
Fast Nationwide Delivery
Dispatch:
1-2 Days
›
Weight per unit
• 0.24 kg
Minimum Order:
12 units
Total:
Each:
Each:
Weight per unit
• 0.24 kg
Minimum Order:
12 units
Total:
Each:
Each:
| Quantity | Discount (%) | Price |
|---|---|---|
| 12 | — | £7.50 |
| 50 | 10 % | £6.75 |
| 100 | 20 % | £6.00 |
| 500+ | 25 % | £5.63 |
Are Also Known As
- Door Shoot Bolt
- Barrel bolt
- Tower bolt
- Spring Shoot Bolt
- Pad bolt
- Sliding bolt
- Panel Bolt
Technical specs
- Overall size: 140mm
- Body width: 25mm
- Bolt diameter: 12mm
- Body thickness: 4mm
Product Overview
Buy the Spring Shoot Bolt K Type direct from Kirmell — a 140mm spring shoot bolt with a narrow 25mm body, engineered for tight-space, high-cycle applications where the bolt housing must sit within a restricted profile and still perform under repeated daily use.
Why Choose the K Type The K Type is the slimmest shoot bolt in the 140mm range. Despite its narrow body, a rolled pin and solid steel bolt rod give it the strength to handle thousands of open-and-close cycles without wearing loose. The angled operating handle allows quick, clean operation even with thick work gloves — a detail that matters on farm gates and yard enclosures used multiple times a day in all weathers.
Typical Applications Livestock cages, trailer tail gates, equestrian enclosures, agricultural gates, machine guarding, fabricated steel assemblies with restricted mounting space.
Also Known As Spring loaded animal bolt, spring gate bolt, animal bolt, sprung loaded bolt.
Technical Specs Overall size: 140mm | Body width: 25mm | Bolt diameter: 12mm | Body thickness: 4mm | Finish: Zinc plated steel | Made in Birmingham, UK
Installation Suitable for welded or bolted installation on steel or wooden frames and fabricated metalwork.
