Spring Swivel Lock ‘H’ – Zinc Plated Steel Spring Locking Mechanism
-
Manufactured in the UK -
Zinc Plated Steel
-
Bulk Discounts Available
-
Fast Nationwide Delivery
Dispatch:
1-2 Days
›
Weight per unit
• 0.14 kg
Minimum Order:
12 units
Total:
Each:
Each:
Weight per unit
• 0.14 kg
Minimum Order:
12 units
Total:
Each:
Each:
Previous Clients.
| Quantity | Discount (%) | Price |
|---|---|---|
| 12 | — | £8.36 |
| 50 | 10 % | £7.52 |
| 100 | 20 % | £6.69 |
| 500+ | 25 % | £6.27 |
Are Also Known As
- Spring Swivel Lock
- Rotary lock
- Rotating Latch
- Spring Loaded Swivel Catch
- Spring Swivel Latch
- Rotating Spring Latch
- Weld-In Spring Swivel Lock
Technical specs
- Overall size: 73mm
- Overall height: 50mm
- Pin diameter: 12mm
- Lock diameter: 20mm
Product Overview
Buy the Spring Swivel Lock H direct from Kirmell — a zinc plated steel weld-in spring swivel lock for machinery guards, access panels, industrial enclosures, fabricated frames, and assemblies where quick engagement and secure spring retention are needed in a compact installation.
Why Choose the H Type? The H type is the most compact swivel lock in the Kirmell range at 73mm overall. The spring-loaded bolt engages automatically when the panel or gate closes, and the rotating swivel catch secures it in position until deliberately released — providing positive retention without needing tools or a separate locking step. The weld-in body integrates directly into the fabricated frame during manufacture for a clean, permanent installation with no visible surface fixings. Manufactured from zinc plated steel for corrosion resistance in industrial and commercial environments.
Typical Applications: machinery guards, access panels, industrial enclosures, fabricated steel frames, stillage lids, cage doors, equipment covers.
Technical Specs Overall size: 73mm | Overall height: 50mm | Pin diameter: 12mm | Lock diameter: 20mm | Weight: 0.14kg | Installation: Weld-in | Finish: Zinc plated steel | Made in Birmingham, UK
